LASER TREE 80W/40W/30W/20W Laser Head For CNC Engraver Wood Cutting DIY Laser Tools 450nm TTL/ PWM Blue Light Laser Module
LASER TREE 80W/40W/30W/20W/7W Laser Head For Engraver Wood Cutting CNC DIY Laser Tool Blue Light Laser Module
LT-4LDS-V2 (20W Optical Power) Features:
The LT-4LDS-V2 is a professional cutting module designed for long-term safe cutting and fine engraving processes. Compared with V1, V2 has been greatly improved with a new housing design, easier-to-use air-assist, longer focal length and more stable cutting output power. Cut 10mm plywood at a time at 3mm/s, easily create the desired effect wood on the pattern. If you spend most of your working time on cutting, then choose LT-4LDS-V2 will be your good companion.
▶4-Beam Compressed Technology, built-in 4pcs 5W beam compressed laser diodes
▶It can cut 10mm thick bass/pine plywood, 8mm thick black acrylic, and even 0.08mm thick stainless steel by just one pass
▶Air assistance performance update;change the diameter of air tube from M5 to M8, to get stronger air pressure at air nozzle
▶ With air assist, when performing laser cutting jobs, an air assist system blows air through the air nozzle, enhancing the cutting performance and reducing the burn marks.
▶ High Precision Engraved Resolution 0.08mm
▶ Widely compatible design, LT-4LDS-V2 laser module can be installed on ZBAIT*,Ortu*,Two Tr**s,Sculpf**9,Atomsta** and other models of DIY laser engraving machines (please contact us if you are not sure about compatibility)
LT-K20 (Optical Power 20W) Features:
LaserTree K20 is a true 19-21W output optical power laser engraving and cutting module. It uses beam compressed technology to combine 4pcs 5W laser diodes into a powerful laser beam with 20W laser power.
2. Powerful Cutting Ability
12mm basswood plywood: 100mm/min, one pass
15mm black acrylic: 15mm/min, one pass
15mm pine wood: 100mm/min, one pass
9mm MDF: 100mm/min, 2 passes
3. Built-in Air Assist Airway & Dual Fan Cooling Design
1>Built-in air assist airway to get clean-cut edges, improve cutting performance.
2>Excellent heat dissipation makes the laser module maintain a stable cutting ability and prolong service life.
4. Working Status Indicator
The electrical connection status can be easily checked by the "Power" and "Signal" LED indicator.
5. Temperature Display & Alarm Function
Excessive working temperatures can reduce the life time of the laser head at an accelerated rate.
LaserTree K20 create a solution with working temperature display,so that you can check the internal temperature of the module easily. When the working temperature of laser module over 55 ℃, it will sound an alarm through the buzzer.
6.Red Cross Line Locating
The working frame can be positioned by red crosshair, it is helpful for improving the convenience of the secondary cutting and engraving as well.
7. Copper Core Protection Lens.
Easy to clean and replace when the lens is contaminated or dusty.
8. Laser View Window
Anti-blue light view window with optical glass material, protective your eye from blue light, no fear of fiames.
9. Widely Compatible Design
In order to improve the compatiblity to different laser engraver machine, K20 provide a solution by adapter board for electric compatibiliy, and sliding plate with multi holes for installation compatibility.
LT-K20 laser module can be installed on Z*aitu,O*tur,Tw* Trees,S*ulpful9, Xtool, A*omstack and other models of DIY laser engraving machines.
